TEAC PA7
TEAC
PA7
- Condition
- Good
- Type
- Line Stage
Ships to you
Posted with tracking, and shipping is included — the price you see is the price you pay. This one takes up to seven days to go out, and you'll get the tracking the moment it does.
Description
Rare vintage preamp, 1980's TypeControl amplifier Input Sensitivity / ImpedancePhono1 MC : 60 μ V/10 Ω, 25 Ω, 100 Ω Phono2 mm : 2.5mV/33k Ω, 47k Ω, 68k Ω / 100 pF, 220 pF, 330 pF Tuner, Aux, Tape play : 200mV/50k ΩMaximum allowable input level (1 kHz)Phono1 MC:5mV Phono2 MM:270mVOutput Level / ImpedancePre out : 1V/75k Ω Rec out : 200mV/68 ΩFrequency characteristicPhono1 MC : 20 Hz to 30 kHz ± 0.2 dB Phono2 mm : 1 Hz to 30 kHz ± 0.2 dB Tuner, Aux, Tape play : 1 Hz to 100 kHz + 0 -0.2 dBSignal-to-noise ratio (A curve)Phono1 MC : 72 dB (input short) Phono2 mm : 90 dB (input short) Tuner, Aux, Tape play : 110 dB (Volume min)Total harmonic distortion factor0.005% (20 Hz to 20 kHz, each input volume max, at maximum output)Tone controlBass : ± 7 dB (100 Hz) Treble : ± 7.5 dB (10 kHz)Turnover frequency340Hz/3.4kHzSubsonic filter12 Hz, -18dB/oct.Channel separation80 dB (1 kHz, Volume max)Audio MutingNoise-canceling headphones-20dBSlew rate± 120 v / μ sec (equalizer amplifier) ± 300 V / μ sec (flat amplifier)Pwer100 VAC, 50Hz/60HzPower consumption60WExternal dimensionsWidth 432x Height 148x Depth 440 mmWeight12kg
Condition notes
Very Good
