Hyperdrive 2

$483

Condition: Mint
Type: Line Stage

Ships to you

Posted with tracking, and shipping is included — the price you see is the price you pay. This one takes up to seven days to go out, and you'll get the tracking the moment it does.

Description

Retail $999 Preamp: 1.0Vrms output into 47kohm at 1kHz has 0.0021% THD, higher output amplitudes will track similarly to HPA output below as signal from HPA is fed to an opamp buffer to driver the preamp outputs. Headphone Amp with 33ohm load: 3.8 mW is 0.0036% THD 30 mW is 0.0036% THD 60 mW is 0.0037% THD 293 mW is 0.0055% THD 620 mW is 0.0072% THD 1.7W is 0.011% THD (Max Power) Intermodulation distortion N/A Power Consumption 1.6W (standby – plugged in) and 12.5W (on) measured at 120Vac Frequency Response Flat within +/-0.5dB from 10Hz to 22kHz Gain 0dB, 6dB, 12dB selectable Noise Preamp: -115dB noise floor referenced to 1.0Vrms at 0dB for preamp output into 47kohm load Headphone Amp: -122dB noise floor referenced to 1.0Vrms at 0dB into 33ohms Maximum Output Sensitivity 1.86Vrms input at 12dB gain setting will produce maximum signal before clipping at the headphone amp output The preamp outputs have -6dB gain applied to them, and so their gains are -6dB, 0dB, and +6dB (corresponding to the 0dB, 6dB, and 12dB gain switch for the headphone amp) at the RCA’s out. Maximum Output of the preamp outs is 3.7Vrms for 1.86Vrms input at the 12dB gain setting. HEADPHONE: Output Power 1.7 Wrms into 33ohms Output Impedance 13 ohms (per TI datasheet for TPA6120A2)

Condition notes

Excellent
